Autel EVO II Series
How does the RTK series differ from the rest of the EVO II lineup?
Unlike standard EVO II models, the RTK edition integrates a high-precision RTK positioning and navigation system.
What is the maximum video transmission range of the RTK Series?
In clear, unobstructed environments without signal interference, the 2.4GHz transmission range extends up to 9 km (FCC) and 5 km (CE).
If the video transmission drops, will the drone continue its real-time mapping mission?
If the image transmission signal temporarily drops, the aircraft will automatically resume mapping once the connection is restored.
What are the display dimensions and resolution of the remote controller?
The remote controller features a built-in 3.26-inch ultra-bright touch screen with a crisp 854×480p resolution.
What RTK base station modes does the system currently support?
The system is currently compatible with the A-RTK base station.
How accurate is the RTK positioning system?
1 cm + 1 ppm (horizontal), 1.5 cm + 1 ppm (vertical)
What is the difference between RTK and PPK, and which mode should I choose?
While both RTK and PPK deliver centimetre-level accuracy, your choice depends on the environment. RTK is ideal for real-time convenience when you have a reliable network connection. If your survey area has poor signal coverage or you don't need real-time data, PPK is the recommended method.
Does the EVO II RTK series capture data in relative or absolute coordinates?
The EVO II RTK provides measurement data in absolute coordinates.
Does the drone camera feature lossless zoom?
The camera achieves up to 4x lossless zoom.
How does the Enterprise Edition differ from standard EVO II models?
Compared to standard EVO II models, the Enterprise Edition adds support for specialized accessories, including a spotlight, loudspeaker, strobe, and RTK module.
Which remote controller comes with the Enterprise Edition?
ommand your fleet with the included Autel Smart Controller, built specifically for the EVO II Enterprise Series. Its 7.9-inch Retina touchscreen uses True Tone technology to deliver a stunning 2048×1536 resolution at a ultra-bright 2,000 nits—four times the brightness of conventional smart devices for effortless direct-sunlight viewing. Best of all, it offers cross-compatibility across other EVO II models.
How many frequency bands does the remote controller support?
902-928 MHz; 2.400-2.4835 GHz; 5.725–5.850 GHz.
Note: Frequency bands vary by country or model.
What is the effective range of the spotlight accessory?
The spotlight provides effective illumination for camera operations up to approximately 30 metres.
Is the spotlight brightness adjustable?
Tap the spotlight icon in the lower-left corner of the live video feed to toggle the light on/off or adjust its brightness level.
How loud is the loudspeaker accessory?
Autel states that testing in a 65 dB ambient environment shows the loudspeaker outputting 120 dB at 1 metre, 88 dB at 60 metres, and 70 dB at 110 metres.
What is the effective range of the night lights?
Depending on environmental conditions, the light has a maximum visibility range of up to 5,000 metres.
How do I change or replace the Enterprise accessories?
Removing Accessories
Ensure the aircraft is powered off.
Loosen the screws on both sides of the accessory and remove it.
Insert both ends of the protective cover back into the corresponding slots.
Attaching Accessories
Ensure the aircraft is powered off.
Gently twist and remove the protective cover from the accessory interface.
Align the accessory screws with the corresponding screw holes, then tighten the screws securely.
How long does it take to fully charge the aircraft battery?
It takes approximately 90 minutes to fully charge each battery.
Can the battery be used in low-temperature environments?
Operating in low-temperature environments will reduce battery life, so plan your flight times accordingly. For optimal battery performance, ensure the battery is warmed to above 15 °C before takeoff.
